| CAP |
Material : Aluminum and plastic |
| |
Display Orientation : Software adjustable Default, +90, +180, and -90 Degrees |
| |
Display Panel Active Area : 1.54″ (39.1mm) |
| |
Display Resolution : 240 x 240 px |
| |
Display Brightness : 300 cd/m² |
| |
Display Panel Type : Transmissive TFT, 262K colo |
| |
|
| WATER BLOCK |
Dimensions:Diameter : 74.7mm H: 55.97mm |
| |
Material:Block : Copper Housing : Plastic |
| |
|
| PUMP |
Motor Speed : 800 – 2,800 ± 300RPM |
| |
Power : 12V DC, 0.3A |
| |
|
| RADIATOR |
Dimensions : 123 x 275 x 30mm |
| |
Material : Aluminum |
| |
|
| TUBE |
Length : 400mm |
| |
Material : Ultra-low Evaporation Rubber with Nylon Braided Sleeve |
| |
|
| FAN |
Model : F120 RGB Core Fans |
| |
Quantity : 2 |
| |
Dimension : 120 x 120 x 26mm |
| |
Speed : 500-1,800 ± 180 RPM |
| |
Air Flow : 78.86 CFM |
| |
Air Pressure : 2.57 mm H2O |
| |
Noise : 33.88 dBA |
| |
Bearing : Fluid Dynamic Bearing |
| |
Power Consumption : 12V DC, 0.2 A, 2.4W |
| |
Connector : 4-pin PWM |
| |
|
| RGB CONTROLLER |
Dimensions : 63.2 x 53.2 x 12.8mm |
| |
Weight : 52.8g |
| |
Mounting : Magnet and 3M Dual Lock |
| |
Connection Cables : 1x USB 2.0 internal connector 1x SATA power cable |
| |
Input Connector : 12V DC / 2.6A |
| |
RGB Lighting Channels : 3 |
| |
Output Channel Voltage : 5V DC |
| |
NZXT RGB Channel Output LED Qty. : Up to 40 LEDs per channel and up to 120 LEDs combined total for the total 3 channels |
| |
|
| COMPATIBLE SOCKET & CPU |
Intel:Intel Socket LGA 1700 & 1200/115X Intel Core i9 / Core i7 / Core i5 / Core i3 / Pentium / Celeron |
| |
AMD:AMD Socket AM5, AM4, sTRX4*, TR4* (*Threadripper bracket not included) AMD Ryzen 9 / Ryzen 7 / Ryzen 5 / Ryzen 3 / Threadripper |
